Photo Index - G. M. Diehl Machine Works, Inc. - number 77

Machinery Photo Index

Manufactured/Badged by:
G. M. Diehl Machine Works, Inc.
Peru, IN, and Wabash, IN

Machine Specifications
Machine Class:	Wood Working Machinery
Machine Type:	Rip Saw
Machine Size:
Submitted By:	larry withers

Machine Specifications
Description/Model:	number 77
Date of Manufacturer:	?
Serial Number:
Last Updated	1/18/2012 11:12:02 AM

Comments:

The machine is located at West Hartford Stair and Cabinet Company in the stair department. The machine you see is a ripping cutting machine to put a tongue on treads and a groove on the risers, you see this in the 6th photo.
