Photo Index - N. A. Woodworth Co. - FC-1422 Cone-Lok Drilling Jig

Machinery Photo Index

Manufactured/Badged by:
N. A. Woodworth Co.
Ferndale, MI

True Manufacturer:
N. A. Woodworth Co., Ferndale, MI

Machine Specifications
Machine Class:	Metal Working Machinery
Machine Type:	Other
Machine Size:
Submitted By:	Mike Beam

Machine Specifications
Description/Model:	FC-1422 Cone-Lok Drilling Jig
Date of Manufacturer:	1950’s?
Serial Number:
Last Updated	11/10/2025 9:44:35 PM

Comments:

Cross drilling jig for round stock utilizing removable drill bushing. Acquired in an auction lot. Note company address is prior to 5 digit zip code use.
